Laboratory Equipment
Confocal microscopes
High-end confocal microscope Leica TCS SP8 with one standard PMT and one sensitive HyD detector. Allows acquisition of fixed and living samples. The environmental chamber PECON with the CO2 regulation provides a suitable atmosphere for living cells experiments. The microscope offers several modes including lambda scanning, FRET and FRAP measurements, and is also equipped with a MATRIX module for object tracking during acquisition (e.g. growing oocytes or roots)
The most up-to-date confocal microscope Zeiss LSM 880 NLO is equipped with a set of lasers for one-photon excitation and with tunable Ti:Sa pulsed laser for two-photon excitation. High-sensitive 32-channel GaAsp spectral detector gets unrivaled clear images. It is possible to do one-channel FLIM (Fluorescence Lifetime IMaging), FCS (Fluorescence Correlation Spectroscopy), and RICS (Raster Image Correlation Microscopy) measurements which allow us to uncover molecular relationships and functions. The microscope works with high speed and high resolution. Live-cell imaging heated chamber with CO2 atmosphere is available as well.
Dosluhující invertovaný konfokální mikroskop Leica TCS SP2 s AOBS (Acousto-Optical Beam Splitter) systémem, zajištujícím vysoký stupeň citlivosti a kombinovatelnosti až čtyř barev fluorescenčních markerů. Mikroskop umožnuje analýzu struktur fixovaných i živých preparátů. Zařízení dovoluje jak multibarevnou analýzu tak fyziologický záznam buněk, 3D rekonstrukci. K dispozici je diodový laser 405 nm pro excitaci v oblasti spektra blízkého UV.
Wide-field microscopes
There is also a great wide-field system Olympus Scan^R available. It is equipped with a stabilized light source, high sensitive Hamamatsu camera, motorized stage, filter, and objective turrets and shutters. It is possible to do high-quality imaging as well as high throughput imaging and mosaic imaging. A high-quality stage chamber with the regulation of temperature (-5 to 65 °C) and gas level (CO2, O2) can maintain also multiwell dishes and allow high throughput imaging under different environmental conditions.
Fully motorized fluorescence wide-field microscope NIKON TiE2 serves for fixed and living samples. It is equipped with a high-speed monochromatic ORCA Flash camera able to get 100 fps as well as with a nice RGB camera. Excitation Cool-LED P-4000 with 16 LEDs cover the full spectrum as well as SEDAT system of emission filters and multiband dichroic. OKOLab environmental chamber suits most common living cells demands. The microscope is driven by the full version of NIS-elements with High Content Imaging possibilities (JOBs module).
A fully automated microscope ZEISS Axioscan Z.1 with the dock for 100 slides can easily and autonomously scan all of them at once. It is a workhorse for High Throughput Imaging of all of your tissue sections which could be reconstructed back to the 3D image of the sample.
Super-resolution microscopes
Microscope Zeiss Elyra PS.1 uses technologies of structured illumination (SIM) and precise localization (PALM/STORM) to overcome the so-called diffraction barrier, which limits us to the resolution of around 200 nm in conventional light microscopy. Nanoscopy allows us to observe structures with 2-3x higher resolution with SIM and up to 5 nm with localization microscopy. The microscope can use a technology of TIRF (Total Internal Reflection Fluorescence) to increase the signal-to-noise ratio in the space near to cover glass. A set of high-quality lasers and cameras help us to make great super-resolution images.
Ligthsheet microscopes
Zeiss Lightsheet Z.1 microscope is great for rapid acquisition of fixed, living, or cleared samples in selective plane illumination. There are two pairs of 5x and 10x illumination objectives. Detection objective of 5x, 10x, 20x, and 40x and two objectives 20x for clearing RI 1.38 and 1.45. The chamber size is roughly 2x2x2 cm. The two-channel acquisition is driven by two cooled PCO cameras.
For optimal performance, all microscopes stay on antivibration tables in air-conditioned rooms. Our core facility serves people of many different fields of research and contributes significantly to results published in peer-reviewed scientific journals.
Reservation
If you are really interested in work with our microscopes, please,
1) join a google group of users.
2) join a VMCF reservation system.
3) Students and employees of Charles University in Prague only: You will need a permission to entry laboratory rooms via chip or your employee card. Fill up this form.
If you are only interested in workshop and other microscopy related events announcements join a group lab.konfmi.
Active users are going to receive lab.konfmi announcements automatically.
!!! sign up to get our newsletters !!!
Price list
| lamp WF | cena s DPH | Rezervace |
| Olympus Cell^R (widefield) | 119 Kč | |
| NIKON TiE2 | 119 Kč | |
| Zeiss Elyra PS.1 (lamp WF) | 119 Kč | |
| Konfokální mikroskopy | ||
| Zeiss LSM 880 | 1198 Kč | |
| Leica TCS SP8 | 1198 Kč | |
| Leica TCS SP2 | 697 Kč | |
| Super Resolution | ||
| Zeiss Elyra PS.1 (superresolution, TIRF, laser WF) | 774 Kč | |
| Zeiss Elyra PS.1 (superresolution, TIRF, laser WF) s assistencí | 1655 Kč | |
| High Throughput Imaging - live cell | ||
| Olympus Scan^R (widefield) | 173 Kč | 505 Kč |
| NIKON TiE 2 | 173 Kč | 505 Kč |
| Leica TCS SP8 (konfokál) | 347 Kč | 505 Kč |
| Zeiss LSM 880 (konfokál) | 347 Kč | 505 Kč |
| High Throughput Imaging - fixed samples | ||
| Olympus Scan^R (widefield) | 85 Kč | 505 Kč |
| NIKON TiE 2 | 85 Kč | 505 Kč |
| Leica TCS SP8 (konfokál) | 135 Kč | 505 Kč |
| Zeiss LSM 880 (konfokál) | 135 Kč | 505 Kč |
| Axioscan – virtual slider | 67 Kč | 505 Kč |
| Lightsheet | ||
| Any sample up to 24 hours | 253 Kč | 505 Kč |
| Long-term experiments (longer than 24 hours) | 127 Kč | 505 Kč |
| Analýza obrazu | ||
| Konzultace | 50 Kč | |
| Rešerše algoritmu / nastavení postupů | 101 Kč | |
| Psaní kódu / manuální analýza | 390 Kč | |
| Strojový čas výpočtů | 469 Kč |
More prices on intranet here.
